System
- Arm® Cortex®-M4F
- Maximum operating frequency: 112MHz
- Supports single FPU
Memory
- Flash: Up to 512KB
- SRAM: 64KB
- 64K Data Flash with ECC
Power Supply and Power Supply Management
- VDD/VDDA range: 2.7~5.5V
- Supports POR/LVR
- Supports LVD
Timers
- 16-bit CFGTMR
- 16-bit LPTMR: 1
- 32-bit LPITMR: 1
- Watchdog timer: 1
- RTC: 1
Analog Peripherals
- 12-bit ADC: 2, External channels: 16+13/16+16
- Comparator with an 8-bit DAC
- PDU: 2
I/Os
- Up to 89 I/Os
- All mappable on external interrupt vectors
Debug Mode
- SWJ-DP
- DWT
- ITM
- TPIU
- FPB
Peripherals
- LPUART: 3
- LPI2C: 1
- LPSPI: 3
- CAN: 3 (all supporting CAN FD)
Security Features
- Encryption Service Engine (CSEc) provides comprehensive encryption functions outlined in the SHE (Secure Hardware Extension) functional specification.
- 128-bit unique device ID
- CRC calculation unit
- Internal watchdog timer (WDT)
- External watchdog timer (EWDT)
- Memory Protection Unit (MPU)
- On-chip memory with full ECC coverage
Package
- LQFP64/100
